EPG 300
Electronic Program Guide system
A reailable,
flexible and powerful
EPG system for broadcasting.
Specifications & Features
- Standard: Fully compliant with the DVB standards and ISO/IEC 13818 International
- Open: System database model, data structure solely on the basis of the DVB standard, national standards and industry standards to create exchange program data and other information, and third-party systems.
- Security: provides a full set of security system design, system authentication to encrypted storage, all-round protection of system security. Sensitive word special handling processes. The strict editorial, audit broadcast process.
- Stability: system support for non-stop operation mode, parameter configuration without having to restart the system to take effect.
- Harmony: Friendly UI interface. Easy to use and fully meet the needs of the development of STB.
- Full-featured: fully meet the definition of the DVB standards and International standards and requirements. The modular design of the system has a high degree of flexibility, and the flexibility to upgrade on demand, personalized secondary development and expansion to meet the needs of the different periods of the system construction.
- Flexibility: You can specify any PID stream broadcast, pause, file output stream for any stream synchronization, easy to coordinate the work of the third-party product development, testing and debugging.
Product performance and indicators
| NO | Function | Performance |
| 1 | Business group packet | 255 |
| 2 | Frequencies | 255 |
| 3 | Channel | 1024 |
| 4 | Program | storage unlimited (EIT Table biggest player next 7-64 days continuously adjustable programs list) |
| 5 | The maximum frequency of single-player card Quantity | 64 |
| 6 | The CAS management | 8 |
| 7 | EIT refresh cycle | <60 seconds (highly superior to offline generated) |
| 8 | SI/PSI table contents refresh cycle | 1 to 600 seconds (continuously adjustable set to refresh mode). |
| 9 | Single the PID-Stream bandwidth | 1kbps ~ 38Mbps (continuously adjustable) |
| 10 | Output method | ASI output or IP output |
| 11 | Play cards export Bandwidth | 1Mbps ~ 180Mbps (continuously adjustable) |
| 12 | Import file function | Support XML and TXT. Automation, intelligent parsing the import file. |
| 13 | PSI / SI table generation function | PAT,CAT,PMT,SDT ,SDT Other, BAT+ SDT,NIT,NIT Other,EIT Present/Follow,EIT Schedule,EIT Other Present/Follow,EIT Other Schedule,TDT,TOT + TDT and other user-defined tables. |
| 14 | Mosaic program navigation | Support for up to 64 single-screen mosaic navigation |
| 15 | OTA STB upgrade function | Yes |
| 16 | System requirement |
|
