LynxCrypt 400
High- Security Conditional Access System for digital TV systems
Telelynx has developed both card-based (LynxCrypt 200) and card-free (LynxCrypt 100) CAS for more than ten years. These CAS’ have been deployed to over 100 systems around the world now with several millions of subscribers relying on the system to watch their favorite TV programs.
Now, with enhanced security demanding from the market, Telelynx is proud to introduce LynxCrypt 400 card-based CAS with an option of high security, which requires smart card-set top box pairing.
Specifications & Features
Key Features
- Support of Simulcrypt and Multicrypt.
- Authorization / De-authorization through event and package.
- OSD and Bmail Messages support multiple languages.
- Support Zone/District controlling.
- STB-Card Paring function (for high security only).
- Optional Master-slave card function.
- Parental Control through PIN code protection.
- Fingerprint from the head-end to control the location, presentation, colors, and fonts.
- OTA STB software upgrade addressable to a single, a series of, or all STBs.
- Pay Per View to support Pay Per Channel (PPC), Pay Per Event(PPV) and Instant Pay-Per-View (IPPV).
- EPG importing supports TXT and XML file.
Performance
- Max carrier per EMMG Link: 32
- Max scrambling channel per carrier: 16
- Max services (or channels): 65535
- Max Events: 65535
- Max EMM/addressable-EMM stored in a smart card: 50
- EMM production speed: 100/sec
- Bandwidth of entitlement: adjustable from 100 to 2000Kbps.
- The EMMI sending EMM capacity: 32Mbps
- SMS interface speed: 2Mbps.
- EMM priority: adjustable and in dynamic mode.
- Max products that can be authorized in a smart card: 512
- Max on-demand number for a card: 255
Note: Specifications are subject to change without prior notice.
